Caolin Bolus Alba Weighing Packing Machine

PUDA recommends screw bagging machine-Caolin Bolus Alba Weighing Packing Machine

Various powder granular material and bulk destiny is 0.1-0.5T/m³
Such as light calcium carbonate, black and white carbon, graphite and kaolin, etc.

packing machine is applicant to ultra-micro fine powder, nanometer class light calcium carbonate, white and black carbon, and Graphite such kind of power and granular materials need to be handled specially.

Specification: Caolin Bolus Alba Weighing Packing Machine made in China

1.Specification: DCS-FWJD, DCS-FWJJ, DCS-FWJS
2.Packing speed:1~3bags/min
3.Accuracy:±0.4%~0.6%
4.Weighing range: 5~10kg 10~25kg 25~50kg
5.Air pressure: 0. 5~0.7Mpa
6.Power supply: 380V 50Hz
7.Power:5.5KW
8.Bulk density: 0.04-0.5 T/m3

Working Principle of Caolin Bolus Alba Weighing Packing Machine:

Materials are fed into buffer bin from finished product hopper and agitated by homogenized system which can efficiently discharge the air contained in materials out of buffer hopper and prevent material forming bridge to make sure continuously packing process. Materials are filled into packing bag through screw controlled by frequency conversion. When filling weight reaches preset value, packing machine will stop feeding, packing bag will be manually taken off, thus single packing is finished. The weighing instrument of FW type packing machine can choose both gross and net weighing packing.

Caolin Bolus Alba Weighing Packing Machine made in China

FAQ:

1. Payment term: T/T in advance. 30% down payment, balance should be paid by T/T or L/C before shipment.
   2. We will do test running and make proper adjustments according to customers' specific requirement before shipment.
   3. Customization is available.
   4. What's the information should I let you know if I want to get a detailed quotation?
   Please advise your products shape (powder, granule, irregular shape), the grain size and weight of each bag ,bag type, type of package material, packing speed and quantity, etc.
   5. Wooden carton package for the machine.
   6. Transformer is provided.
   7. Technical manual in English is provided.
   8. Optional devices can be added to link with our machines.
   9. One year warranty.

Definition of Kaolin

Kaolin is a non-metallic mineral, a kind of clay and clay rock dominated by kaolinite clay minerals. Because it is white and delicate, it is also called white cloud soil. It is named after Gaoling Village, Jingde Town, Jiangxi Province.

The pure kaolin is white, fine, soft and soft, with good plasticity and fire resistance. Its mineral composition is mainly composed of kaolinite, halloysite, hydromica, illite, montmorillonite, quartz, feldspar and other minerals. Kaolin has a wide range of uses. It is mainly used in papermaking, ceramics and refractory materials, followed by coatings, rubber fillers, enamel glazes and white cement raw materials, and a small amount is used in plastics, paints, pigments, grinding wheels, pencils, daily cosmetics, soap, Pesticide, medicine, textile, petroleum, chemical, building materials, national defense and other industrial sectors.

Main ingredients:

Kaolin minerals are composed of kaolinite cluster minerals such as kaolinite, dickite, pearlite and halloysite. The main mineral component is kaolinite.

The crystalline chemical formula of kaolinite is 2SiO2·Al2O3·2H2O, and its theoretical chemical composition is 46.54% SiO2, 39.5% Al2O3, and 13.96% H2O. Kaolin minerals belong to the 1:1 type layered silicate. The crystals are mainly composed of silicon-oxygen tetrahedrons and sodium hydroxide octahedrons. The silicon-oxygen tetrahedrons are connected in a two-dimensional direction to form a hexagonal arrangement with a common vertex angle. In the grid layer, the apex oxygen not shared by each silicon-oxygen tetrahedron faces one side; the apex oxygen of the silicon-oxygen tetrahedron layer and the oxygen-assisting octahedron layer common silicon-oxygen tetrahedral layer forms a 1:1 unit layer

Physical and chemical properties：Caolin Bolus Alba Weighing Packing Machine

Properties: more dull, white and fine when pure, and gray, yellow, brown and other colors when it contains impurities. Depending on the origin, the appearance can be loose soil blocks and compact rock blocks.

Density: 2.54-2.60 g/cm3.

Melting point: about 1785°C.

With plasticity, wet soil can be molded into various shapes without breaking, and can remain unchanged for a long time [1].

Origin of the deposit：

Kaolin is a common and very important clay mineral in nature. It is formed by weathering of feldspar or other silicate minerals in igneous rocks and metamorphic rocks in acidic media lacking alkali metals and alkaline earth metals.

Soil classification：

The minerals contained in kaolin in nature are mainly divided into clay minerals and non-clay minerals. Among them, clay minerals mainly include kaolinite group minerals and a small amount of montmorillonite, mica and chlorite; non-clay minerals mainly include feldspar, quartz and hydrated hydrates, and some iron minerals such as hematite and chalcogenite. Iron ore, limonite, etc., titanium minerals such as rutile, and organic matter such as plant fibers. It is mainly clay minerals that determine the properties of kaolin.

Cause classification：

On the basis of the genesis of kaolin deposits, according to the differences in mineralization geology, geographical conditions, deposit scale, ore body shape and occurrence characteristics, and ore material composition embodied by different mineralization processes, the "Guidelines for Geological Exploration of Kaolin Mines" will Kaolin deposits in China are divided into three types and six subtypes.

1. Weathering type: It is divided into weathering residual subtype and weathering leaching subtype;

2. Hydrothermal alteration type: It is divided into hydrothermal alteration subtype and modern hot spring alteration subtype;

3. Sedimentary type: It is divided into sedimentary and sedimentary-weathering subtypes and kaolinite claystone subtypes in coal-bearing strata .

Industry Type：

According to its texture, plasticity and sand quality scores are divided into three types:

1. Hard kaolin: hard, no plasticity, plasticity after crushing and fine grinding.

2. Soft kaolin: soft, strong plasticity, sand mass fraction <50%;

3. Sandy kaolin: soft in nature, weak in plasticity, sandy mass fraction>50% [2].

Caolin Bolus Alba Weighing Packing Machine made in China
