25kg Valve Bag Titanium Dioxide Packing Machine And Mixing Machine

25kg valve bag titanium dioxide packing machine and mixing machine





Description of machines:

The DCS –FZKJ type final packing machine made in our company adopts Japanese UNIPLUSE Company's F701C type weighing controller andSIEMENS'sSMART200 programmable controller, their features are high accurate and stable, with complete functions, and are easy for operation. They are applied mainly to all kind of materials final packing. It is capable of finishing all control proceeding besides fitting on bags manually.

DCS-FZKJ Type Functions and Features：

This type of machine is designed to package extremely light and fine powders with low bulk density and high air ridden. The vacuum chamber and the bulk/trim flow system draw product into the bag at uniform rates, providing excellent filling accuracy, tight package, and non-dusty environment.



Technical specifications:

Item	Parameter	Remark
Model	DCS-25
Working voltage	AC400V/50HZ	Three-phase four-wire system,fluctuate<±10%
Working air pressure	0.5～0.7MPa	Air Consumption :0.6m³/min(compressed air)
Operating temperature	5～50℃
power dissipation	≤9.2KW
material	titanium dioxide	Particle size,10-50μm bulk density：0.8kg/m³, White Color
Packing s	0-25㎏/bag
Speed	60-100bag/h
Weighing range	≤±100g/bag
