25KG 50KG Fluorspar Powder Packaging Machine

China cheap price of 25KG 50KG Fluorspar Powder Packaging Machine

Product Application of 25KG 50KG Fluorspar Powder Packaging Machine:

PUDA DCS series packing machine adopts high precision screw feeding measurement.

Suitable for open packaging of powdery materials with poor fluidity.

Representative materials such as flour, rare earth, bentonite, starch, chemical powder, etc.

Technical data of 25KG 50KG Fluorspar Powder Packaging Machine:

Weighing range: 10-50kg

Packing speed: 1-4 bags/minute (depending on the characteristics of packaging materials and different packaging bags)

Measuring accuracy: ±0.2 ~ 0.4%

Applicable voltage: AC22OV-440V 50/60HZ three-phase four-wire (customers need to provide local voltage level and frequency)

Air source requirements: the pressure is 0.4-0.8Mpa dry compressed air, the total air consumption is 0.4m3/min

Applicable environment: Altitude ≤2000 meters, ambient humidity ≤95% (no condensation), operating temperature 0℃ ~ 50℃, design storage temperature -20℃ ~ 70℃

Working process of PUDA 25KG 50KG Fluorspar Powder Packaging Machine:

This kind of machine adopts of frequency conversion speed control spiral feeding, the material from the finished product warehouse uniformly through the spiral operation of the material supply to the quantitative weighing system.

After starting the packaging machine, the spiral operation begins to fill the packing bag or weighing hopper on the weighing system. When the material reaches the preset quantitative value, the spiral stops feeding, and the packing bag completed by weighing is taken down manually, that is, the first packaging is completed.

Parameters and function list:of 25KG 50KG Fluorspar Powder Packaging Machine:

Features of 25KG 50KG Fluorspar Powder Packaging Machine:

According to the characteristics of powder, granule, etc all kinds of material and the use of different requirements, tailored.

The equipment choose different according to different materials, such as dc, twisted dragon, vibration, belt) hierarchical form of material feeding, equipment performance is stable, the packaging of high precision, fast;

Programmable electronic control system, the control process of highly reliable;

Dust dust removal of advanced design, reduce the working environment of dust pollution;

Weighing system for electronic platform scale type metering, adopt comprehensive digital calibration and parameters setting, have weight measuring cumulative display and automatic peeling and automatic zero gap, automatic correction function, such as high sensitivity, strong anti-jamming capability.

Instrument equipped with communication interface to facilitate online networking, real-time monitoring and network management for packaging machine;

Clip package including pneumatic hook system, adding back into the air, feed measurement control mechanism, hydraulic lifting mechanism, electric control, etc.

PUDA Service of 25KG 50KG Fluorspar Powder Packaging Machine:

1.Providing professional installation instructions and video of troubleshoot.
2. Providing machine control software updates and operation teaching in our factory.
3. Two years free maintenance for touch screen, inverter, PLC, temperature controller , photoelectric sensor with freight prepaid.
4.Engineers available to service the machinery overseas, buyers pay 100 US dollars daily service fees and travel expenses.
5.Pick-up services at Hebei airport, providing packaging solutions and testing material on machines, full refund if unsatisfied with the machine.

Operation training:

1:Machine is very easy operate, delivery with manual, offer lot of photo and video when machine in assembling or disassembling.

2: Welcome to our factory learning.

3: Engineers available to service machinery overseas.
