25kg 50kg Open Packaging Machine

25kg 50kg Open Packaging Machine with best quality

1. The basic design of the packaging machine (DCS-BD) is based on the following requirements put forward by the demander as an important basis for acceptance.
2. Material particle size: minimum material ≤0.1 micron, maximum particle < 15mm. Material water content less than 1%, bulk gravity: ≤1800kg/m3.

3. Design voltage requirements: AC380±10%/50Hz, design total power, 12kw/ set, equipment weight about 800kg.
4. The equipment is equipped with the number of bags and weight on-site accumulation display and PLC interface function
5. The segregation rate of materials before and after packaging is ≤±0.3%, and the limit segregation is ±0.5%. Post noise ≤50dB, limit deviation ≤65dB.
6. Small bag bag 20~40kg, bag size width 450mm x height 600~750mm, the material is made of plastic braid open pocket.
7. Packing machine feeding method: belt type, weighing method: bucket type.
8. Design efficiency: 365 days/year, 2 shifts/day,8 hours/shift, 8760 hours/year, 85% opening rate, output: 19-22 tons/hour.
9. Packaging weighing method: manual bagging, automatic bag clamping, automatic weighing, automatic filling, self-sealing.
10. Weighing range 20~40kg/bag, weighing error: ≤±0.2 ~ 0.4%, 40kg/bag packing speed: 550bags/H.
