Highlights Calcium Carbonate Packaging Machine

China's  25kg Highlights Calcium Carbonate Packaging Machine Manufacturer

Performance characteristics of packaging scale:

• The powder packing machine is an integration of machine, electricity, light and instrument, controlled by single chip microcomputer, with automatic quantitative, automatic filling, automatic adjustment of measurement error and other functions

• Fast speed: the use of screw blanking, light control technology

• High precision: using stepping motor and electronic weighing technology

• Wide packaging range: the same quantitative packaging machine can adjust and change the feeding screw of different specifications within 5-5000g by electronic scale keyboard

• A wide range of application: a certain fluidity of powder, granular materials can be

• suitable for bag, can, bottle and other kinds of packaging container powder quantitative packaging

• The error caused by the change of material density and material level can be tracked and corrected automatically

• Photoelectric switch control, only manual bagging, bag mouth clean, easy to seal

• The parts in contact with the material are made of stainless steel, which is convenient to clean and prevent cross contamination

• Feeding device can be configured, which is more convenient for users

Main technical parameters of belt conveyor:

Conveyor length: 3 meters

Conveyor width :450mm

Transmission distance: 3 meters

Transmission width :400mm

Conveyor height: 200-500 adjustable

Conveyor power: 380V-0.55KW

Transmission speed: 0.4m per second

Main technical parameters of bale sewing machine:

High sewing speed: 1500 RPM

Working speed: synchronous with the belt conveyor

Thickness of large sewing: 6mm

Packing distance: 5-10mm

Machine needle model: 92*230

Working principle of this packing machine:

Automatic quantitative packing scale is applied to automatic quantitative packing of industrial and agricultural production. The whole weighing process is controlled by computer and completed automatically. With fast weighing speed; Weighing accuracy is high, labor-saving, labor-saving, simple operation and convenient maintenance. When the quantitative packing scale enters the automatic operation state, the weighing control system opens the feeding door and starts feeding. The feeding device is a fast and slow two-stage feeding mode. When the weight of the material reaches the set value of fast feeding, stop fast feeding and keep slow feeding; When the material weight reaches the final set value, close the feeding door and complete the dynamic weighing process; At this time, the system detects whether the bag clamping device is in a predetermined state. When the bag is clamped tightly, the system sends a control signal to open the unloading door of the weighing hopper, and the material enters the packing bag. After the material is released, the unloading door of the weighing hopper will be automatically closed. Loose the bag clamping device after unloading the empty material, and the bag will fall automatically. Sew the bag after it falls and transfer it to the next station. This cycle is repeated automatically.

Highlights Calcium Carbonate Packaging Machine is a state-of-the-art equipment for handling and packaging calcium carbonate with high efficiency and safety. Its unique explosion-proof design ensures maximum protection against the risk of explosions and fire, making it an ideal choice for calcium carbonate handling in hazardous environments.

The machine's explosion-proof design includes several key features such as an anti-static system, which prevents the buildup of static electricity that could trigger an explosion, a grounding system that reduces the risk of electrical discharge, and a spark extinguishing system that detects and extinguishes sparks before they can ignite.

In addition, the machine's sealing mechanism and air filtration system ensure that no dust or airborne particles escape during the packaging process, further reducing the risk of explosions and fire. The machine's safety sensors and alarms also provide real-time monitoring of the packaging process, alerting operators to any potential hazards or malfunctions.

Finally, the machine is made of high-quality, durable materials that are resistant to corrosion and wear, ensuring long-lasting performance and reliability. Overall, Highlights Calcium Carbonate Packaging Machine is a safe and dependable solution for handling and packaging calcium carbonate, providing peace of mind and confidence in operation.
