25kg 50kg Barite Bagging machine

DCS-FCQ Series: Air Forced Packer for Valve Bag--25kg 50kg Barite Bagging machine

Product Description:

This series of machines are designed for Packing Mixture with Powders and Granules, Granular Materials into Valve Bags, the Advantage is Fast Packing Speed and High Accuracy. Representative Materials are Barite, Silicon Sand, Calcined Flint Clay, Active Carbon, Refractory Materials, and Dry Mortar etc.

Technical Parameters of 25kg 50kg Barite Bagging machine：

● Weighing Range: 10-50 kg

● Packing Rate: 3-8 bags/minute (packing speed depends on the material features and packing bags)

● Weighing Accuracy: ± 0.2-0.6％

● Applicable Voltage: AC22OV-440V 50/60HZ Three Phases and Four Lines (Clients should supply the voltage class and frequency at their local place)

● Air Source Requirement: 0.4-0.8MPa Dry Compressed Air,Total Air Consumption: 0.4m³/min

● Applicable Environment: Altitude≤2000meters, Humidity≤95% RH Non-congealable Dew, Operating Temperature:0℃～50℃, Storage Temperature : -20℃～70℃

Working Principle of 25kg 50kg Barite Bagging machine：

DCS-FCQ series packing machine using forced air to sweep materials. When the materials in boiling hopper reaches high level, valve on the top of hopper closes. Under the enclosed circumstance, materials are swept into packing bag by the strong wind with low pressure from outside the hopper. Meantime mechanical and electronic parts cooperate together to control the materials within the target range, finishing the packing and metering.

FAQ: 25kg 50kg Barite Bagging machine：

1.Payment term: T/T in advance. 30% down payment, balance should be paid by T/T or L/C before shipment.
2. We will do test running and make proper adjustments according to customers' specific requirement before shipment.
3. Customization is available.
4. What's the information should I let you know if I want to get a detailed quotation?
Please advise your products shape (powder, granule, irregular shape), the grain size and weight of each bag ,bag type, type of package material, packing speed and quantity, etc.
5. Wooden carton package for the machine.
6. Transformer is provided.
7. Technical manual in English is provided.
8. Optional devices can be added to link with our machines.
9. One year warranty.

How easy is the operation of  25kg 50kg Barite Bagging machine：

1. Check whether the equipment is in good condition: check whether the components of the valve pocket automatic bag packing machine are complete and intact, and whether there is any defect or loosening. If so, handle it first.
2. Adjust the equipment: put the bag into the machine, and adjust the automatic bag clamping and automatic cutting mechanism to make it conform to the size and shape of the bag.
3. Turn on the power and adjust the packaging machine: turn on the power of the packaging machine, turn on the switch of the packaging machine, and then adjust the speed and temperature to ensure the quality of the packaging.
4. Put the products: put the products that need to be packaged into the valve pocket one by one, paying attention to the placement and quantity of the products.
5. Skilled operation: skilled operation of the bag clamping machine, and master the packaging speed and temperature, adjust the best packaging effect to ensure product quality.

Matters needing attention of 25kg 50kg Barite Bagging machine：
1. Parts and workpieces in the packaging machine must be thoroughly cleaned and disinfected to avoid secondary contamination of the product.
2. The user of the packaging machine must be familiar with the operation methods and relevant safety knowledge of the equipment to prevent accidents.
3. In the process of adjusting and using the packaging machine, special attention should be paid to whether abnormal noise or other abnormal phenomena are generated.
4. The packaging machine requires frequent maintenance and maintenance to maintain the normal operation of the equipment.
5. Ensure that the valve pocket is clean and dry, and strictly control the sealing temperature of the valve pocket to prevent the valve pocket from deformation or improper sealing.
