50kg Activated Carbon Filing Packaging Machine

DCS-FCQ Series: Air Forced Packer for Valve Bag--50kg activated carbon filing Packaging Machine

1. Product Description of 50kg activated carbon filing Packaging Machine

This series of machines are designed for Packing Mixture with Powders and Granules, Granular Materials into Valve Bags, the Advantage is Fast Packing Speed and High Accuracy. Representative Materials are Barite, Silicon Sand, Calcined Flint Clay, Active Carbon, Refractory Materials, and Dry Mortar etc.

2. Technical Parameters of 50kg activated carbon filing Packaging Machine

● Weighing Range: 10-50 kg

● Packing Rate: 3-8 bags/minute (packing speed depends on the material features and packing bags)

● Weighing Accuracy: ± 0.2-0.6％

● Applicable Voltage: AC22OV-440V 50/60HZ Three Phases and Four Lines (Clients should supply the voltage class and frequency at their local place)

● Air Source Requirement: 0.4-0.8MPa Dry Compressed Air、Total Air Consumption: 0.4m³/min

● Applicable Environment: Altitude≤2000meters, Humidity≤95% RH Non-congealable Dew, Operating Temperature:0℃～50℃, Storage Temperature : -20℃～70℃

3．Working Principle of 50kg activated carbon filing Packaging Machine

DCS-FCQ series packing machine using forced air to sweep materials. When the materials in boiling hopper reaches high level, valve on the top of hopper closes. Under the enclosed circumstance, materials are swept into packing bag by the strong wind with low pressure from outside the hopper. Meantime mechanical and electronic parts cooperate together to control the materials within the target range, finishing the packing and metering.

Quantitative packaging machine weighing hopper gravity quantitative packaging automatic weighing instrument as a control, the single scale can hold 280-300 bags of yellow sand per hour, and the double scale can hold 600 bags of yellow sand per hour. One bag of 100 catties, of course, the number of catties can be adjusted, the sewing machine automatically seals the bag with yellow sand, coal weighing, bagging and sealing as one machine. Function: filling, metering, packing, filling, and sealing. The machine uses a large-capacity hopper that can hold about two cubic meters of sand at a time; the hopper is three-sided and high, and the other side is convenient for forklifts to use; the sand bagging machine is to avoid sand It is hollow without feeding, and a silo wall rapper is installed on the silo wall to assist sand discharge, which is efficient and saves manpower.

For the sand packing machine, we will make the material opening for you according to the size of your bag. Of course, you can also select the bag according to our conventional discharge opening. The discharge opening of our batch is 273mm in diameter, and the bag is 50 cm in diameter. 80 cm wide and long is suitable, of course, it will be set according to the number of catties per bag.

Service:

Overview of activated carbon:

Activated carbon is a specially treated charcoal that heats organic raw materials (husks, coal, wood, etc.) in the absence of air to reduce non-carbon components (this process is called carbonization), and then reacts with gas, and the surface is Corrosion produces a structure with well-developed micropores (this process is called activation). Because the activation process is a microscopic process, that is, the surface erosion of a large number of molecular carbides is point erosion, so the activated carbon surface has countless small pores. The diameter of the micropores on the surface of activated carbon is mostly between 2-50nm. Even a small amount of activated carbon has a huge surface area. The surface area of activated carbon per gram is 500~1500m2. Almost all applications of activated carbon are based on this feature of activated carbon.

Activated carbon is prepared by pyrolysis and activation processing of carbon-containing raw materials such as wood, coal and petroleum coke. It has developed pore structure, large specific surface area and abundant surface chemical groups, and has strong specific adsorption capacity. A collective term for carbon materials. [2]

Usually powder or granular porous amorphous carbon with strong adsorption capacity. Solid carbonaceous material (such as coal, wood, hard nut shell, fruit core, resin, etc.) is carbonized at a high temperature of 600 to 900 ℃ under air isolation, and then is carbonized with air, carbon dioxide, water vapor or at 400 to 900 ℃. The mixed gas of the three is obtained after oxidation activation. [3]

Carbonization volatilizes substances other than carbon. Oxidation activation can further remove residual volatile substances, create new and expand original pores, improve microporous structure, and increase activity. Carbon activated at low temperature (400°C) is called L-carbon, and carbon activated at high temperature (900°C) is called H-carbon. H-carbon must be cooled in an inert atmosphere, otherwise it will be transformed into L-carbon. The adsorption performance of activated carbon is related to the chemical properties of the gas during oxidation activation and its concentration, activation temperature, activation degree, the composition and content of inorganic substances in activated carbon and other factors, and it mainly depends on the nature of the activated gas and the activation temperature.

The carbon content, specific surface area, ash content and pH value of its aqueous suspension of activated carbon all increase with the increase of activation temperature. The higher the activation temperature, the more complete the volatilization of residual volatile substances, the more developed the microporous structure, and the greater the specific surface area and adsorption activity. [3]

The ash composition and content in activated carbon have a great influence on the adsorption activity of carbon. Ash content is mainly composed of K2O, Na2O, CaO, MgO, Fe2O3, Al2O3, P2O5, SO3, Cl-, etc. The ash content is related to the raw materials used to make activated carbon, and with the removal of volatiles in the carbon, the ash content in the carbon increases. Big. [3]

As of 2007, the world's annual output of activated carbon reached 900kt, of which coal-based (quality) activated carbon accounted for more than 2/3 of the total output; while China's annual output has exceeded 400kt, ranking first in the world. The United States, Japan, etc. are also the world's major producers of activated carbon .
