25kg Silica Valve Bag Packing Machine

China's factory of 25kg Silica Valve Bag Packing Machine

Product Description of 25kg Silica Valve Bag Packing Machine:

Open packaging machine - 25kg valve pocket packaging machine - four-head packaging machine Application scope: Suitable for quantitative packaging of various granular materials, block materials, and powder materials (the specific feeding method varies, and it needs to be customized according to different materials). The open 25kg valve pocket four-head packaging machine is an efficient and reliable automated packaging equipment specially designed for the packaging of large quantities of products. This machine adopts advanced control technology and high-precision weighing system to ensure extremely high precision and efficiency during the packaging process. The packaging machine is usually equipped with a drip-proof and leakage-proof device to ensure a clean packaging process and avoid material waste. Its stainless steel structure makes the machine easy to clean and resistant to the erosion of various highly corrosive materials. The operation interface is user-friendly, allowing operators to quickly learn and operate the machine. Safety-wise, an emergency stop button is provided to respond quickly in case of unexpected situations. In summary, the open 25kg valve pocket four-head packaging machine provides a reliable and efficient solution for the packaging of large quantities of products. As a professional packaging machine for large quantities of products, it not only improves production efficiency but also ensures the consistency of product quality, making it an ideal choice for modern industrial enterprises.

Application of the 25-kilogram valve bag packaging machine: It is used for the transportation, packaging, storage and packaging of powder, granular and block-like items in fields such as food, grains, chemicals and mineral products.

Technical data of 25kg Silica Valve Bag Packing Machine:

Bag-making method: Pillow-type bag
Packaging speed: 2 - 60 bags per minute
Bag size: (50 - 460) × (80 - 350) mm (length × width)
Machine weight: 800 Kg
Power supply: 3 KW, 380V ±10%, 50Hz
Dimensions: 1420 × 1530 × 1830 (length × width × height)
Compressed air requirements: 0.6 MPa, 0.36 m³/min

Main Product features of 25kg Silica Valve Bag Packing Machine:

• Integrated multi-functional design, saving space and significantly reducing energy consumption of the constant temperature and humidity packaging room.
• The air quality and dust control are better, with no risk of clogged pipes or dust spilling out.
• It features automatic platform height adjustment, automatic sample collection, and automatic unhooking functions, thereby reducing labor intensity and risks.
• Higher measurement accuracy, enhancing packaging efficiency;
• Optimize the operating environment by adopting designs such as mobile touch screens, which are easy to use and convenient to operate.

25kg valve bag packaging machine, reaction vessel weighing bag equipment usage:
1. Before packaging: Place the empty pallet on the packaging position under the weighing platform.
2. Bagging: Start the equipment. The bagging device automatically grabs the bag and clamps the filling opening, keeping it in a sealed state. The lifting frame automatically rises to the position set by the operator, which is suitable for packaging this type of bag.
3. Skinning: The packaging machine automatically removes the weight from the packaging bag.
4. Quick Feeding: The packaging machine automatically activates the gravity-based feeding mechanism. During the feeding process, the weighing instrument continuously measures the weight of the materials in the packaging bag. When the weight of the materials in the bag reaches the preset quick feeding quantity value, the quick feeding process ends.
5. Slow feeding: Once the fast feeding process is completed, the packaging machine automatically switches to slow feeding mode. When the slow feeding reaches the set quantity, the feeding process ends and the packaging machine automatically stops the feeder.
6. Discharging: After the filling process is completed, when the filled packaging bags have landed on the tray, the workers will press the conveyor button to start the conveyor, and then the bags will be transported out of the packaging position. At this point, the forklift will come to transport the tray away.
